PCB Inline V-cut PCB Separator Machine for "#" Shape

PCB Inline V-cut PCB Separator Machine for "#" Shape Features:

※Workable for “#”shape depaneling.

※Horizontal and vertical depaneling is optional.

※Blade set can be quickly changed.

※Could connect PCB loader and PCB unloader to realize fully automated production to save labor.

※Simple operation, workers can operate it after training.

※Unique new blade design, lifetime should be increased by 1.5-2 times.

※Safety: Sensor is used to ensure safe production.


PCB Inline V-cut PCB Separator Machine for "#" Shape Specification:

Blade dimension

Circular blade:80 60mm

Linear Blade: 356×43.5×6mm

PCB width

300mm(could be customized)

Driven mode

Stepping / Servo motor(optional)

V-cut angel

>40°

Cutting speed

300-500/s

Blade material

High speed steel

Air pressure

0.5-0.8Mpa

Voltage

220/110V

Dimension

12501560mm×800mm×1295mm

Packaging weight

300kgs


If you need the machine,please contact us:

WhatsApp/Wechat(Bunny):  +86 136 8490 4990
